安裝要點:

供電電源為交流110V和交流220V兩種接法,注意不同的接線端子。繼電器輸出觸點只能連接在交流220V及以下的系統(tǒng),過高的電壓可能會損壞該觸點。接近感應開關和碼盤的配合要合適,距離過遠可能會造成丟碼。傳感器的信號線盡量遠離動力線。
調(diào)試要點(必要的3步)
A、請設定對應脈沖的系數(shù)
B、請檢查電機運行方向和顯示方向是否一致如果不一致請交換傳感器的A、B信號輸入線
C、請設定在當前位置希望顯示的數(shù)值

Installation important:
Power source AC 110V AC 220V two-connection, note the different terminals. Relay output contacts can only be connected in the system up to the AC 220V, excessive voltage can damage the contacts. Proximity switch and codingappropriate co-ordination, is too far may result in losing yards. As far as possible from power cables from the signal of the sensor.
Debugging elements(essential 3 step)
A、 The coefficient a, set the corresponding pulse.
B、 Check that the motor direction and the direction is consistent; if not, swap sensors a, b signal input line.
C、 Set the values you want to display in the current location.
